ACP SHEET

ACP SHEET Specification

Protective Film
pvdf coating

Usage
wall cladding, Indoor, Outdoor

Feature
Weather Resistant

Material
Aluminum

Dimension (L*W*H)
32 Foot (ft)

Surface Treatment
PE Coated

Coating Thickness
2 Millimeter (mm)

Panel Thickness
3 Millimeter (mm)

Aluminum Thickness
0.25 Millimeter (mm)

Tensile Strength
2 Kilopascals (KPa)

Yield Strength
7+1 sevice coat

Color
Blue and grey ALL COLOR

Application
Exterior & Interior

ACP SHEET Trade Information

Minimum Order Quantity
10 Square Foots

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Square Foots Per Month

Delivery Time
5 Days

Sample Available
No

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
1. this sheet packaging also lamminates tape on sheet sheet- 8*4 , 10*4 , 12*4. 2. Sheet Protection: Protective Film: PE or LDPE film on the top surface (with brand print or arrow direction) Removable after installation Interleaf Paper/Plastic Sheet: Between each ACP sheet to prevent scratches Edge Protection: Foam or cardboard edge guards to protect corners 3. Outer Packaging: Wrapping: Entire bundle wrapped with stretch film or shrink wrap Strapping: Plastic or metal straps for bundle reinforcement Wooden Pallet or Crate (Optional): Especially used for export or long-distance shipping Pallet/crate may be fumigated and ISPM-15 certified for export compliance 4. Labeling on Each Bundle: Product name & grade (e.g., PE or FR) Dimensions (thickness width length) Quantity (number of sheets) Color / finish / batch number Manufacturer/brand name Production date & serial number Handling symbols (fragile, stack limits, keep dry, etc.)

Main Domestic Market
All India

Certifications
In ACP we certfied with WONDER ALU BOARD & TIMEX BOND.

About ACP SHEET

ACP Sheet Aluminium Composite Panel Description

ACP Sheets (Aluminium Composite Panels) are modern, lightweight, and durable cladding materials composed of two thin layers of aluminium enclosing a non-aluminium core, typically made of polyethylene (PE) or fire-retardant (FR) material. They are widely used in both interior and exterior architectural applications due to their aesthetic appeal, structural strength, and weather resistance.

Key Features:

Lightweight & Strong: High strength-to-weight ratio for easy handling and installation.
Weather & UV Resistant: Withstands harsh environmental conditions without fading or warping.
Smooth & Stylish Finish: Available in a wide range of colors, textures, and finishes (solid, metallic, mirror, brushed, marble, wooden).
Thermal & Sound Insulation: Offers good insulation properties due to the core material.
Fire-Resistant Options: Available in FR Grade with fire-retardant mineral core.
Low Maintenance: Resistant to dust, dirt, and stains easy to clean.

Typical Structure:


Aluminium Layer (Top) Protective Coating / PVDF or PE Coating Adhesive Film Polyethylene (PE) or Fire-Retardant (FR) Core Adhesive Film Aluminium Layer (Bottom) Protective Film

Common Applications:

Building facades & curtain walls
Interior wall cladding & false ceilings
Signage and display panels
Modular kitchens & partitions
Corporate branding & kiosks

Standard Specifications:

Property	Value / Range
Panel Thickness	3 mm, 4 mm, 5 mm, 6 mm
Aluminium Skin Thickness	0.25 mm to 0.5 mm (per side)
Core Material	PE (Polyethylene) or FR (Fire-Retardant)
Standard Panel Size	1220 2440 mm / 1500 3050 mm / Custom sizes
Surface Coating	PVDF (Exterior) / PE (Interior)
Finishes Available	Glossy, Matte, Brushed, Wooden, Mirror, etc.

Would you like a custom version for signage, construction bidding specs, or branding purposes?

The Commercial Aluminium Composite Panel is a perfect solution for outdoor use as it is highly weather-resistant. The panel is made of high-quality aluminum material and is available in blue and grey colors. The surface of the panel is coated with PE, which makes it more durable and long-lasting. It is an ideal choice for commercial buildings, shopping malls, and other outdoor structures due to its weather-resistant properties. This panel is lightweight and easy to install, making it an excellent choice for architects and builders. It is available in different sizes and thicknesses, making it suitable for various projects. The Commercial Aluminium Composite Panel is a cost-effective solution that provides both durability and aesthetic appeal to any outdoor structure.

FAQs of Commercial Aluminium Composite Panel:

Q: What is the material of the Commercial Aluminium Composite Panel?

A: The Commercial Aluminium Composite Panel is made of high-quality aluminum material.

Q: Can I use the Commercial Aluminium Composite Panel for outdoor projects?

A: Yes, the panel is highly weather-resistant and is suitable for outdoor use.

Q: What is the surface treatment of the Commercial Aluminium Composite Panel?

A: The surface of the panel is coated with PE, which makes it more durable and long-lasting.

Q: What are the available colors of the Commercial Aluminium Composite Panel?

A: The panel is available in blue and grey colors.

Q: What type of businesses can use the Commercial Aluminium Composite Panel?

A: The Commercial Aluminium Composite Panel is suitable for retailers, service providers, suppliers, and traders who are looking for a cost-effective solution for their outdoor projects.
